ABMA
Leakage Current Measuring Adapter
Accessory for measuring leakage current and patient auxiliary current with a multimeter
Overload protection by means of PTC:
As opposed to a fuse link, the PTC resets itself automatically after being tripped and then disconnected from the input circuit.
The ABMA leakage current measuring adapter serves as an attachment for TRMS multimeters for the measurement of touch voltage per VDE 0100-710 (replacement for DIN VDE 0107, paragraph 10), and for the measurement of continuously flowing leakage current and patient auxiliary current per DIN EN 62353: 2014 and IEC 60601-1: 2005/A1: 2012 (Medical electrical equipment – Part 1: General requirements for basic safety and essential performance).
- 1 leakage current measuring adapter
- 1 set of operating instructions
- 1 calibration report
Input
- Input current: 0 … 50 mA AC, DC
- Measuring shunt: 1 kΩ, 1.0%
- Overload protection: PTC
- Max. input current: 150 mA AC, DC
Output
- Output voltage: 0 … 50 V (1 V/mA) AC, DC
- Output resistance: 10 kΩ
- Frequency response per EN 60601-1
Safety
- Measuring category: CAT III 300 V
Connections
- Input: Two 4 mm safety sockets, clearance: 19 mm in accordance with the standard
- Output: Two 4 mm safety plugs, clearance: 19 mm in accordance with the standard
