The safety tester is used in combination with SECUTEST test instruments for testing 3-phase devices after repair (DIN VDE 0701), as well as for periodic testing (DIN VDE 0702).

It allows for fully automated or manual testing in accordance with the menu-driven test sequences included with the test instruments, with transmission of test results to, and data analysis at SECUTEST test instruments (SECUTEST SII with feature F01).

DIN VDE tests without mains operation

• Protective conductor resistance, insulation resistance, equivalent leakage current.

DIN VDE tests with mains operation

• Differential current, contact current.

Equipped with 5-pole CEE 32 A (max. 20 A) and CEE 16 A

Dimensions: 290 x 120 x 105 mm, weight: approx. 2.4 kg
