METRISO PRIME+
5000 V Insulation Measuring Instrument, Digital
Instrument for conventional insulation measurement with selectable voltages of up to 5000 V – Developed and manufactured for all known types of long-term insulation measurement as well
- Extensive measuring range from 0.4 MOhm…1 TOhm
- Variable test voltage or in fixed steps 100 V, 250 V, 500 V, 1.0 kV, 1.5 kV, 2.0 kV, 2.5 kV, 5.0 kV
- Polarization index and absorption ratio
- Voltage measurements up to 1000 V
- Frequency measurement 15 Hz … 1 kHz
- Capacitance measurement 0.1 … 5 F
- Measurement of electrical discharge
- Guard terminal for compensating surface current
- Mains power supply or via battery pack
- Backlit dot-matrix display
- Digital display of measured values and limit values
- Timer function 1 s … 100 min
- Data logger function
- DAkkS calibration certificate
1 high-voltage insulation measuring instrument with permanently connected measurement cables and test probes,
2 alligator clips (5 kV version)
1 mains power cable and 1 interface cable
1 operating instructions
- Universal insulation measuring instrument
- Digital indicator in illuminated display
- Integrated timer
- RS 232 interface
- Special high-voltage measurement cables
- Integrated memory saves up to 1600 measuring values
- Contact current measurement
- Voltage measurement to 1000 V AC/DC
- Measurement of breakdown voltage
- Capacitance measurement
- Time-dependent insulation measurement, e.g. polarization index and absorption ratio, dielectric discharge, capacitance meas.
- DAkkS calibration certificate
